Detail Produk

Pixel pitch 12mm Module size(mm) 192 x 192mm
Pixel configuration 2R1G1B or 1R1G1B Module density 16 x 16dots
View Angle 120°/90° Pixel density 6,944dots/㎡
LED encapsulation DIP 346 Refresh rates ≥ 1200Hz
Driving Method 1/4 scan,constant current Max power consumption 850w/㎡
Cabinet size Normal 960x 960mm or Designed by requirements Cabinet material Aluminum alloy or Iron, Steel
Cabinet thickness < 8 cm or Designed by requirements Cabinet weight < 12kg/cabinet or Designed by require
Brightness >6500nits Type Power consumption 400w/㎡
Working voltage AC110 / 220V +- 15% Working temp -20℃to +60℃
Best viewing distance >10 m - 300meter Working humidity  10%~90%
LED parameters R:620-625nm IV:1000-1300mcd MTBF  > 5,000hours
G:520-523nm IV:2,400-2,700mcd Gray Level  > 8192 grade
B:467-470nm IV:550-700mcd Lifespan  > 100,000hours
  • Weight 1000 g
  • Dimensions 35 × 30 × 7 cm
  • Color Black, Pink, Red, White
